数据插入

本节介绍用于插入点、边的方法。

属性类型映射

嬴图属性类型和Go数据类型的映射关系如下：

^[1] 支持的日期字符串格式包括[YY]YY-MM-DD HH:MM:SS、[YY]YY-MM-DD HH:MM:SSZ、[YY]YY-MM-DDTHH:MM:SSZ、[YY]YY-MM-DDTHH:MM:SSXX、[YY]YY-MM-DDTHH:MM:SSXXX、[YY]YY-MM-DD HH:MM:SS.SSS以及它们的变体。

示例图结构

本节示例的点、边插入和删除基于如下的Schema和属性定义进行：

参考此示例创建这个图结构。

InsertNodes()

向图中某个Schema插入点。

参数

• schemaName: str：Schema名称。
• nodes: []*structs.Node：待插入的点列表。
• confg: *configuration.RequestConfig（可选）：请求配置。

返回值

• Response：请求结果。
• error：包含操作过程中遇到的任何问题的错误对象；如果操作成功，则返回nil。

// Inserts two 'user' nodes into the graph 'social'

requestConfig := &configuration.RequestConfig{
    Graph: "social",
}

insertRequestConfig := &configuration.InsertRequestConfig{
    RequestConfig: requestConfig,
}

nodes := []*structs.Node{
    {
    	ID: "U1",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name":            "Alice",
        		"age":             18,
        		"score":           65.32,
        		"birthday":        "1993-5-4",
        		"active":          0,
        		"location":        "point({latitude: 132.1, longitude: -1.5})",
        		"interests":       []string{"tennis", "violin"},
        		"permissionCodes": []int32{2004, 3025, 1025},
      		},
    	},
    },
    {
    	ID: "U2",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name": "Bob",
      		},
    	},
  	},
}

response, _ := driver.InsertNodes("user", nodes, insertRequestConfig)
if response.Status.Code.String() == "SUCCESS" {
    fmt.Println(response.Status.Code)
} else {
    fmt.Println(response.Status.Message)
}

SUCCESS

InsertEdges()

向图中某个Schema插入边。

参数

• schemaName: str：Schema名称。
• edges: []*structs.Edge：待插入的边列表；每个Edge的From和To字段必填。
• confg: *configuration.RequestConfig（可选）：请求配置。

返回值

• Response：请求结果。
• error：包含操作过程中遇到的任何问题的错误对象；如果操作成功，则返回nil。

// Inserts two 'follows' edges to the graph 'social'

requestConfig := &configuration.RequestConfig{
    Graph: "social",
}

insertRequestConfig := &configuration.InsertRequestConfig{
    RequestConfig: requestConfig,
}

edges := []*structs.Edge{
    {
    	From: "U1",
    	To:   "U2",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"createdOn": "2024-5-6",
        		"weight":    3.2,
      		},
    	},
  	},
  	{
    	From: "U2",
    	To:   "U1",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"createdOn": 1715169600,
      		},
    	},
  	},
}

response, _ := driver.InsertEdges("follows", edges, insertRequestConfig)
if response.Status.Code.String() == "SUCCESS" {
    fmt.Println(response.Status.Code)
} else {
    fmt.Println(response.Status.Message)
}

SUCCESS

InsertNodesBatchBySchema()

通过gRPC向图中某个Schema插入点。此方法针对批量插入进行了优化。

参数

• schema: *structs.Schema：目标Schema；字段Name必填，Properties包含图中对应Schema关联的部分或所有属性。
• nodes: []*structs.Node：待插入的点列表；每个Node的Values字段必须与Schema.Properties结构相同。
• confg: *configuration.RequestConfig（可选）：请求配置。

返回值

• InsertResponse：插入请求结果。
• error：包含操作过程中遇到的任何问题的错误对象；如果操作成功，则返回nil。

// Inserts two 'user' nodes into the graph 'social'

requestConfig := &configuration.RequestConfig{
    Graph: "social",
}

insertRequestConfig := &configuration.InsertRequestConfig{
    RequestConfig: requestConfig,
}

schema := &structs.Schema{
    Name: "user",
    Properties: []*structs.Property{
    	{Name: "name", Type: ultipa.PropertyType_STRING},
    	// {Name: "age", Type: ultipa.PropertyType_INT32},
    	{Name: "score", Type: ultipa.PropertyType_DECIMAL, DecimalExtra: &structs.DecimalExtra{Precision: 25, Scale: 10}},
    	{Name: "birthday", Type: ultipa.PropertyType_DATETIME},
    	{Name: "active", Type: ultipa.PropertyType_BOOL},
    	{Name: "location", Type: ultipa.PropertyType_POINT},
    	{Name: "interests", Type: ultipa.PropertyType_LIST, SubTypes: []ultipa.PropertyType{ultipa.PropertyType_STRING}},
    	{Name: "permissionCodes", Type: ultipa.PropertyType_SET, SubTypes: []ultipa.PropertyType{ultipa.PropertyType_INT32}},
    },
}

nodes := []*structs.Node{
    {
    	ID: "U1",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name": "Alice",
        		// "age":             18,
        		"score":           65.32,
        		"birthday":        "1993-5-4",
        		"active":          false,
        		"location":        types.NewPoint(132.1, -1.5),
        		"interests":       []string{"tennis", "violin"},
        		"permissionCodes": []int32{2004, 3025, 1025},
      		},
    	},
    },
    {
    	ID: "U2",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name": "Bob",
        		// "age":             nil,
        		"score":           nil,
        		"birthday":        nil,
        		"active":          nil,
        		"location":        nil,
        		"interests":       nil,
        		"permissionCodes": nil,
      		},
    	},
    },
}

insertResponse, err := driver.InsertNodesBatchBySchema(schema, nodes, insertRequestConfig)
if err != nil {
    log.Fatalf("Insert failed: %v", err)
}

if insertResponse != nil && len(insertResponse.ErrorItem) > 0 {
    fmt.Println("Error items:", insertResponse.ErrorItem)
} else {
    fmt.Println("All nodes inserted successfully")
}

All nodes inserted successfully

InsertEdgesBatchBySchema()

通过gRPC向图中某个Schema插入边。此方法针对批量插入进行了优化。

参数

• schema: *structs.Schema：目标Schema；字段Name必填，Properties包含图中对应Schema关联的部分或所有属性。
• edges: []*structs.Edge: 待插入的边列表；每个Edge的From和To字段必填；每个Edge的Values字段必须与Schema.Properties结构相同。
• confg: *configuration.RequestConfig（可选）：请求配置。

返回值

• InsertResponse：插入请求结果。
• error：包含操作过程中遇到的任何问题的错误对象；如果操作成功，则返回nil。

// Inserts two 'follows' edges into the graph 'social'

requestConfig := &configuration.RequestConfig{
    Graph: "social",
}

insertRequestConfig := &configuration.InsertRequestConfig{
    RequestConfig: requestConfig,
}

schema := &structs.Schema{
    Name: "follows",
    Properties: []*structs.Property{
    	// {Name: "createdOn", Type: ultipa.PropertyType_TIMESTAMP},
    	{Name: "weight", Type: ultipa.PropertyType_FLOAT},
    },
}

edges := []*structs.Edge{
    {
    	From: "U1",
    	To:   "U2",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		// "createdOn": "2024-5-6",
                "weight": float32(3.2),
      		},
    	},
  	},
  	{
    	From: "U2",
    	To:   "U1",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		// "createdOn": 1715169600,
        		"weight": nil,
      		},
    	},
  	},
}

insertResponse, err := driver.InsertEdgesBatchBySchema(schema, edges, insertRequestConfig)
if err != nil {
  	log.Fatalf("Insert failed: %v", err)
}

if insertResponse != nil && len(insertResponse.ErrorItem) > 0 {
  	fmt.Println("Error items:", insertResponse.ErrorItem)
} else {
  	fmt.Println("All edges inserted successfully")
}

All edges inserted successfully

InsertNodesBatchAuto()

通过gRPC向图中一个或多个Schema插入点。此方法针对批量插入进行了优化。

参数

• nodes:List[Node]：待插入的点列表；每个Node的Schema必填，所有点的Values结构相同并且包含图中对应Schema关联的所有属性。
• confg: *configuration.RequestConfig（可选）：请求配置。

返回值

• map[string]*http.InsertResponse：Schema名称，插入请求结果。
• error：包含操作过程中遇到的任何问题的错误对象；如果操作成功，则返回nil。

// Inserts two 'user' nodes and a 'product' node into the graph 'social'

requestConfig := &configuration.RequestConfig{
    Graph: "social",
}

insertRequestConfig := &configuration.InsertRequestConfig{
    RequestConfig: requestConfig,
}

nodes := []*structs.Node{
    {
    	Schema: "user",
    	ID:     "U1",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name":            "Alice",
        		"age":             18,
        		"score":           65.32,
        		"birthday":        "1993-5-4",
        		"active":          false,
        		"location":        types.NewPoint(132.1, -1.5),
        		"interests":       []string{"tennis", "violin"},
        		"permissionCodes": []int32{2004, 3025, 1025},
      		},
    	},
  	},
  	{
    	Schema: "user",
    	ID:     "U2",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name":            "Bob",
        		"age":             nil,
        		"score":           nil,
        		"birthday":        nil,
        		"active":          nil,
        		"location":        nil,
        		"interests":       nil,
        		"permissionCodes": nil,
      		},
    	},
  	},
  	{
    	Schema: "product",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"name":  "Wireless Earbud",
        		"price": float32(93.2),
      		},
    	},
  	},
}

result, err := driver.InsertNodesBatchAuto(nodes, insertRequestConfig)
if err != nil {
  	log.Fatalf("Insert failed: %v", err)
}

for schemaName, insertResponse := range result {
  	if len(insertResponse.ErrorItem) > 0 {
    	fmt.Println("Error items of", schemaName, "nodes:", insertResponse.ErrorItem)
  	} else {
    	fmt.Println("All", schemaName, "nodes inserted successfully")
  	}
}

All product nodes inserted successfully
All user nodes inserted successfully

InsertEdgesBatchAuto()

通过gRPC向图中一个或多个Schema插入边。此方法针对批量插入进行了优化。

参数

• edges: List[Edge]：待插入的边列表；每个Edge的Schema、From和To必填，所有边的Values结构相同并且包含图中对应Schema关联的所有属性。
• confg: *configuration.RequestConfig（可选）：请求配置。

返回值

• map[string]*http.InsertResponse：Schema名称，插入请求结果。
• error：包含操作过程中遇到的任何问题的错误对象；如果操作成功，则返回nil。

// Inserts two 'follows' edges and a 'purchased' edge into the graph 'social'

requestConfig := &configuration.RequestConfig{
    Graph: "social",
}

insertRequestConfig := &configuration.InsertRequestConfig{
  	RequestConfig: requestConfig,
}

edges := []*structs.Edge{
  	{
    	Schema: "follows",
    	From:   "U1",
    	To:     "U2",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"createdOn": "2024-5-6",
        		"weight":    float32(3.2),
      		},
    	},
  	},
  	{
    	Schema: "follows",
    	From:   "U2",
    	To:     "U1",
    	Values: &structs.Values{
      		Data: map[string]interface{}{
        		"createdOn": 1715169600,
        		"weight":    nil,
      		},
    	},
  	},
  	{
    	Schema: "purchased",
    	From:   "U2",
    	To:     "684bd6a70000020020000001",
  	},
}

result, err := driver.InsertEdgesBatchAuto(edges, insertRequestConfig)
if err != nil {
  	log.Fatalf("Insert failed: %v", err)
}

for schemaName, insertResponse := range result {
  	if len(insertResponse.ErrorItem) > 0 {
    	fmt.Println("Error items of", schemaName, "edges:", insertResponse.ErrorItem)
  	} else {
    	fmt.Println("All", schemaName, "edges inserted successfully")
  	}
}

All follows edges inserted successfully
All purchased edges inserted successfully

完整示例

package main

import (
	"fmt"
	"log"

	"github.com/ultipa/ultipa-go-sdk/sdk"
	"github.com/ultipa/ultipa-go-sdk/sdk/configuration"
	"github.com/ultipa/ultipa-go-sdk/sdk/structs"
	"github.com/ultipa/ultipa-go-sdk/sdk/types"
)

func main() {
	config := &configuration.UltipaConfig{
		// URI example:	Hosts: []string{"mqj4zouys.us-east-1.cloud.ultipa.com:60010"},
		Hosts:    []string{"192.168.1.85:60061", "192.168.1.87:60061", "192.168.1.88:60061"},
		Username: "<usernmae>",
		Password: "<password>",
	}

	driver, err := sdk.NewUltipaDriver(config)
	if err != nil {
		log.Fatalln("Failed to connect to Ultipa:", err)
	}

	// Inserts two 'user' nodes, a 'product' node, two 'follows' edges, and a 'purchased' edge into the graph 'social'

	requestConfig := &configuration.RequestConfig{
		Graph: "social",
	}

	insertRequestConfig := &configuration.InsertRequestConfig{
		RequestConfig: requestConfig,
	}

	nodes := []*structs.Node{
		{
			Schema: "user",
			ID:     "U1",
			Values: &structs.Values{
				Data: map[string]interface{}{
					"name":            "Alice",
					"age":             18,
					"score":           65.32,
					"birthday":        "1993-5-4",
					"active":          false,
					"location":        types.NewPoint(132.1, -1.5),
					"interests":       []string{"tennis", "violin"},
					"permissionCodes": []int32{2004, 3025, 1025},
				},
			},
		},
		{
			Schema: "user",
			ID:     "U2",
			Values: &structs.Values{
				Data: map[string]interface{}{
					"name":            "Bob",
					"age":             nil,
					"score":           nil,
					"birthday":        nil,
					"active":          nil,
					"location":        nil,
					"interests":       nil,
					"permissionCodes": nil,
				},
			},
		},
		{
			Schema: "product",
			ID:     "P1",
			Values: &structs.Values{
				Data: map[string]interface{}{
					"name":  "Wireless Earbud",
					"price": float32(93.2),
				},
			},
		},
	}

	edges := []*structs.Edge{
		{
			Schema: "follows",
			From:   "U1",
			To:     "U2",
			Values: &structs.Values{
				Data: map[string]interface{}{
					"createdOn": "2024-5-6",
					"weight":    float32(3.2),
				},
			},
		},
		{
			Schema: "follows",
			From:   "U2",
			To:     "U1",
			Values: &structs.Values{
				Data: map[string]interface{}{
					"createdOn": 1715169600,
					"weight":    nil,
				},
			},
		},
		{
			Schema: "purchased",
			From:   "U2",
			To:     "P1",
		},
	}

	result_n, err := driver.InsertNodesBatchAuto(nodes, insertRequestConfig)
	if err != nil {
		log.Fatalf("Insert failed: %v", err)
	}

	for schemaName, insertResponse := range result_n {
		if len(insertResponse.ErrorItem) > 0 {
			fmt.Println("Error items of", schemaName, "nodes:", insertResponse.ErrorItem)
		} else {
			fmt.Println("All", schemaName, "nodes inserted successfully")
		}
	}

	result_e, err := driver.InsertEdgesBatchAuto(edges, insertRequestConfig)
	if err != nil {
		log.Fatalf("Insert failed: %v", err)
	}

	for schemaName, insertResponse := range result_e {
		if len(insertResponse.ErrorItem) > 0 {
			fmt.Println("Error items of", schemaName, "edges:", insertResponse.ErrorItem)
		} else {
			fmt.Println("All", schemaName, "edges inserted successfully")
		}
	}
}
